In the current photovoltaic grid-connected power generation sector, challenges such as fluctuating sunlight intensity, unstable power generation voltage, difficulties in grid integration, and harsh outdoor environments often lead to low grid-connected efficiency, poor equipment reliability, high energy loss, and significant grid impact risks. These issues directly affect the output capacity and grid stability of photovoltaic power stations. To address these challenges, Hongwei Power focuses on the core needs of photovoltaic grid integration and develops customized power transformer solutions. The core objective is to achieve efficient photovoltaic energy conversion and stable grid connection through high-adaptability, high-performance transformer equipment, thereby solving power compatibility issues throughout the photovoltaic grid integration process. This approach helps photovoltaic power stations reduce costs, improve efficiency, and ensure safe, long-term operation.

Product Type: Grid-connected Power Transformer (Oil-immersed or Dry type optional)

Applications: Distributed PV plants, centralized PV plants, commercial/industrial rooftop PV systems, large-scale household PV grid-connection projects

Voltage range: Low voltage (0.4kV, PV module output) to high voltage (10kV/35kV, grid connection). Grid connection standards for photovoltaic power stations of various scales, compatible with mainstream PV module generation parameters.

Core features: High efficiency, energy-saving, wide voltage adaptability, shock resistance, low loss, and intelligent monitoring. Suitable for complex working conditions such as significant light fluctuations, outdoor extreme temperatures, high humidity, and high altitude, as well as long-term continuous operation scenarios.

Additional configurations: Intelligent monitoring module, lightning and explosion protection devices, high-efficiency cooling system, full-process safety protection for photovoltaic grid integration, and real-time operational status monitoring requirements.

1. High-efficiency Energy Saving and Loss Reduction: Featuring nanocrystalline alloy cores and high-conductivity copper windings, this design optimizes core laminations and winding processes to achieve over 98% energy conversion efficiency. Compared to traditional transformers, it reduces iron and copper losses by more than 30%, significantly cutting photovoltaic transmission losses and boosting both power generation and profitability of solar power plants.

2. Wide-range adaptive stable power generation: Capable of wide voltage and frequency adaptation, it precisely matches voltage fluctuations caused by varying light intensity in photovoltaic modules (within ±15% range). This system stably integrates solar power without requiring additional voltage regulation equipment, ensuring uninterrupted power output.

3. Enhanced Impact and Operational Stress Resistance: The equipment features reinforced structural design to improve voltage surge and short-circuit resistance, effectively mitigating instantaneous current surges during PV grid integration and grid reverse surges. It also operates reliably in extreme outdoor conditions including-40℃ to +50℃ temperatures, high humidity, and high altitudes, with operational reliability far exceeding industry standards.

4. Precise Grid Integration for Compatibility: By optimizing transformer impedance characteristics and wiring configurations to precisely meet grid connection standards, this approach minimizes compatibility risks between photovoltaic power and the grid. It effectively prevents voltage distortion and frequency deviation during grid connection, ensuring smooth and stable integration that complies with grid connection specifications.

1. Smart O&M with Easy Management: Featuring an IoT-enabled monitoring module, it collects real-time core data including transformer voltage, current, temperature, and load. The system supports remote data transmission and fault prediction, achieving 98% fault localization accuracy. This significantly reduces O&M complexity and costs while enabling intelligent lifecycle management of equipment.

2. Customized scenario adaptation: Tailored to actual requirements including photovoltaic power station scale, module type, grid connection level, and installation environment, the system provides customized transformer capacity, voltage level, and cooling mode (natural cooling, forced oil circulation, or air cooling), supporting both distributed and centralized photovoltaic grid-connected projects.

3. Comprehensive safety protection: Equipped with advanced lightning protection, explosion-proof, fireproof, and insulation devices, the optimized equipment sealing structure prevents outdoor dust and moisture intrusion, eliminates leakage and fire hazards, and ensures safe operation throughout the grid-connected process of photovoltaic power stations.

Core Issues of Grid-connected Photovoltaic Systems, Transformer Solutions, and Their Value

The photovoltaic power conversion efficiency is low, and the transmission loss is large. By adopting high-efficiency energy-saving core and winding technology, the iron loss and copper loss are reduced, and the power conversion efficiency is improved. The power waste is reduced, the actual power generation of the power station is increased, and the enterprise income is increased.

Voltage fluctuations caused by light variations lead to unstable voltage and interrupted power generation. With wide voltage adaptability, it can handle voltage fluctuations of photovoltaic modules, ensure stable power reception, maintain continuous power generation, and prevent production loss due to voltage fluctuations.

The grid-connected instantaneous current surge causes equipment damage and grid instability. To mitigate these risks, the system incorporates shock-resistant and short-circuit-resistant structural designs with optimized impedance characteristics, protecting transformers and core photovoltaic power station equipment while reducing grid impact risks.

Outdoor harsh environments (high and low temperature, high humidity, etc.) lead to unstable operation and short service life of equipment. The equipment adopts weather-resistant materials and reinforced sealing design, which is suitable for wide temperature conditions. The equipment's ability to withstand harsh working conditions is improved, and the service life is extended by more than 30%, and the equipment replacement cost is reduced.

Photovoltaic power often struggles with grid compatibility, making grid connection difficult and prone to regulatory violations. By precisely aligning with grid access standards and optimizing grid integration performance, we ensure compliant and seamless grid connection, effectively avoiding issues like failed grid detection or repeated rectifications.

The equipment is difficult to maintain, and fault diagnosis is not timely. The built-in intelligent monitoring module supports remote monitoring and fault warning, shortens the time for fault diagnosis and maintenance, reduces the operation and maintenance labor cost, and ensures the continuous operation of the power station.

1. Pre-sales phase: Our technical team conducts one-on-one consultations, conducts on-site inspections of photovoltaic power stations, and provides customized transformer design solutions with grid integration recommendations based on plant planning, module specifications, and grid requirements, ensuring the solutions meet actual needs.

2. Mid-sales phase: We provide end-to-end services including transformer production progress tracking, on-site installation guidance, wiring and commissioning, grid connection testing, and technical training. Our support covers equipment installation, system integration, and grid connection acceptance to ensure swift equipment deployment.

3. Post-sales service: We provide lifetime technical support, including regular equipment inspections, rapid fault response and maintenance, as well as equipment upgrades. We regularly issue maintenance guidelines and promptly resolve operational issues, ensuring long-term stable and efficient grid-connected power generation for photovoltaic power stations.

This dedicated grid-connected photovoltaic power transformer solution centers on high-performance, highly adaptable transformer equipment. It precisely addresses core challenges in photovoltaic grid integration, including energy loss, voltage fluctuations, grid compatibility, and adaptation to harsh operating conditions. By leveraging energy-efficient, stable, and intelligent product advantages, combined with full-cycle professional services, it provides secure, efficient, and compliant grid power support for various photovoltaic power stations. This solution helps photovoltaic enterprises reduce production and operation costs, enhance productivity and profitability, and drive high-quality development in the new energy photovoltaic industry.
